Chicago Pneumatic CP6910-P24 1″ IMPACT WRENCH

Original price was: $2,006.88.Current price is: $1,384.75.

CP6910-P24 – Powerful, Durable & Comfortable

SKU: 6151590070 Categories: , Brand:

Description

CP6910-P24

CP6910-P24 – Powerful, Durable & Comfortable

Benefits

  • Ideal for a variety of heavy Industrial Maintenance applications
  • Reliable & powerful oil bath Pinless Rocking Dog clutch
  • Operator comfort with many ergonomic features
  • 3-part construction reducing downtime maintenance

    • Features

  • 1″ Industrial Pistol impact wrench
  • Oil Bath Pinless rocking dog clutch
  • Durable Aluminum body & Rubber protective cover on clutch housing
  • D-type side handle with Rubber grip
  • Dual (hole & ring) type socket retainer
  • Removable hole plate for suspension
  • Metal trigger & reverse knob for longer durability
  • 3-positions regulator & easy reverse

    •
    Model CP6910-P24
    Part number 6151590070
    Length 290 mm 11.4″
    Length 11.4″ 290 mm
    Net weight 10.2 kg 22.5 lb
    Net weight 22.5 lb 10.2 kg
    Side to center 55 mm 2.2″
    Side to center 2.2″ 55 mm
    Actual air consumption 40.2 cfm
    Actual air consumption 19 l/s 40.2 cfm
    Air inlet thread size 1/2 “
    Min. hose size 13 mm 1/2″
    Min. hose size 1/2″ 13 mm
    Sound pressure 97 db(A)
    Sound Power 108 db(A)
    Vibration ISO ISO-28927-2
    Vibration 8.9 m/s²
    Vibration uncertainty (K) 2.5 m/s²
    Handle type Pistol
    Square drive 1″
    Working Torque Range (fwd) 500 – 2,100 Nm 370 – 1,550
    Working Torque Range (fwd) 370 – 1,550 ft.lbs 500 – 2,100
    Maximum Torque (reverse) 2600 Nm 1920 ft.lbs
    Maximum Torque (reverse) 1920 ft.lbs 2600 Nm
    Free speed 5000 rpm
    Blows per minute 650
    Power/weight ratio 254.9 Nm/kg 85.3 ft.lb/lb
    Power/weight ratio 85.3 ft.lb/lb 254.9 Nm/kg
    VST2 37.7
    Socket retainer Dual (hole+friction)
    Clutch type Pinless Rocking Dog – Oil bath
    European Standards EN ISO 11148-6:2013
