Chicago Pneumatic CP7782TL-6 TORQUE LIMITED 1" IMPACT WRENCH
Chicago Pneumatic CP7782TL-6 TORQUE LIMITED 1" IMPACT WRENCH
Chicago Pneumatic CP7782TL-6 TORQUE LIMITED 1" IMPACT WRENCH - Image 2
Chicago Pneumatic CP7782TL-6 TORQUE LIMITED 1" IMPACT WRENCH - Image 3
Chicago Pneumatic CP7782TL-6 TORQUE LIMITED 1" IMPACT WRENCH - Image 4
Chicago Pneumatic CP7782TL-6 TORQUE LIMITED 1" IMPACT WRENCH - Image 5
Chicago Pneumatic CP7782TL-6 TORQUE LIMITED 1" IMPACT WRENCH - Image 6

Chicago Pneumatic CP7782TL-6 TORQUE LIMITED 1″ IMPACT WRENCH

Original price was: $1,456.70.Current price is: $1,114.38.

CP7782TL-6 – 1″ impact wrench with torque limited in forward – No more overtightening

SKU: 8941077827 Categories: , Brand:

Description

CP7782TL-6

CP7782TL-6 – 1″ impact wrench with torque limited in forward – No more overtightening

Benefits

  • Torque limited
  • Powerful in reverse
  • High operator comfort
  • High durability
  • Shock absorbing
  • Safe
  • Convenient

    • Features

  • 1 position torque limited in forward around 370 ft.lbs / 500 Nm
  • 1920 ft.lbs / 2600 Nm max torque (3 setting positions)
  • Ergonomic D-handle with full teasing trigger
  • Pinless closed reinforced rocking dog mechanism
  • Rubber bumper protecting both applications & tool (included)
  • Socket retainer ring combined with hole retainer
  • Ergonomic handle

    •
    Model CP7782TL-6
    Part number 8941077827
    Length 510.8 mm 20.11″
    Length 20.11″ 510.8 mm
    Net weight 11.6 kg 25.55 lb
    Net weight 25.55 lb 11.6 kg
    Height 171.8 mm 6.76″
    Height 6.76″ 171.8 mm
    Width 210.6 mm 8.29″
    Width 8.29″ 210.6 mm
    Average air consumption 10 cfm
    Average air consumption 4.8 l/s 10 cfm
    Actual air consumption 40.7 cfm
    Actual air consumption 19.2 l/s 40.7 cfm
    Air inlet thread size 1/2 “
    Min. hose size 13 mm 1/2″
    Min. hose size 1/2″ 13 mm
    Sound pressure 100 db(A)
    Sound Power 111 db(A)
    European Sound standard ISO 15744
    Sound uncertainty 3 db(A)
    Vibration ISO ISO-28927-2
    Vibration 7.8 m/s²
    Vibration uncertainty (K) 1.8 m/s²
    Square drive 1″
    Working Torque Range (fwd) 400 – 440 Nm 295 – 325
    Working Torque Range (fwd) 295 – 325 ft.lbs 400 – 440
    Maximum Torque (reverse) 2600 Nm 1920 ft.lbs
    Maximum Torque (reverse) 1920 ft.lbs 2600 Nm
    Free speed 5200 rpm
    Blows per minute 500
    Power/weight ratio 257.4 Nm/kg 86.5 ft.lb/lb
    Power/weight ratio 86.5 ft.lb/lb 257.4 Nm/kg
    Bolt size M32
    European Directives 2006/42/EC (17/05/2006)
    European Standards EN ISO 11148-6:2013
