Chicago Pneumatic CP85030 AIR HYDRAULIC JACK 30T
Chicago Pneumatic CP85030 AIR HYDRAULIC JACK 30T
Chicago Pneumatic CP85030 AIR HYDRAULIC JACK 30T - Image 2
Chicago Pneumatic CP85030 AIR HYDRAULIC JACK 30T - Image 3
Chicago Pneumatic CP85030 AIR HYDRAULIC JACK 30T - Image 4
Chicago Pneumatic CP85030 AIR HYDRAULIC JACK 30T - Image 5
Chicago Pneumatic CP85030 AIR HYDRAULIC JACK 30T - Image 6

Chicago Pneumatic CP85030 AIR HYDRAULIC JACK 30T

Original price was: $2,962.28.Current price is: $2,266.15.

CP85030 – High Lifting Capacity high Durability, safety

SKU: 8941085030 Categories: , Brand:

Description

CP85030

CP85030 – High Lifting Capacity high Durability, safety

Benefits

  • High Lifting Capacity
  • High Durability
  • Fast and easy operation controlled from the handle
  • Low Profile
  • Convenient
  • Easy maneuvering and to transport
  • Safety

    • Features

  • Maximum height: 16.1 in. / 409 mm
  • Air powered piston
  • Includes 2 extensions for higher lifting – Stored on handle for transport
  • Piston and pump
  • Anti dust seals
  • Ideal for easily accessing lifting points on low chassis trucks and buses
  • Convenient joystick controls
  • Cylinder mounted carrying handle
  • 4 ¼ ft./ 1.3 m / long handle bar (1 piece handle) allows easy access to controls when fully positioned under vehicle
  • Handle bar locks in 3 positions: 45°, 90° & 180°
  • Large & soft rubber wheels

    •
    Model CP85030
    Part number 8941085030
    Net weight 38 kg 83.7809523809524 lb
    Net weight 83.7809523809524 lb 38 kg
    Dimension A 150 mm 5.90322580645161″
    Dimension A 5.90322580645161″ 150 mm
    Dimension B 176 mm 6.94222222222222″
    Dimension B 6.94222222222222″ 176 mm
    Dimension C 290 mm 11.4739130434783″
    Dimension C 11.4739130434783″ 290 mm
    Dimension D 240 mm 9.46285714285714″
    Dimension D 9.46285714285714″ 240 mm
    Dimension E 86 mm 3.3762962962963″
    Dimension E 3.3762962962963″ 86 mm
    Dimension F 223/289  8.8/11.4
    Dimension F 8.8/11.4 223/289
    Dimension G 1365 mm 53.76″
    Dimension G 53.76″ 1365 mm
    Capacity 30 / 15  33.1
    Capacity 33.1 short ton(s) 30 / 15 ton(s)
    Dimension D+E 326 mm 12.8424242424242″
    Dimension D+E 12.8424242424242″ 326 mm
    Dimension P 71 mm 2.79630769230769″
    Dimension P 2.79630769230769″ 71 mm
    Wheel type Rubber
    UPC Code 015451767945
