Chicago Pneumatic MR25-480-KL ATEX
$1,665.30
Standard reversible vane motor, ATEX certified and lubrication free
- Description
- Additional information
Description
MR25-480-KL-ATEX
Standard reversible vane motor, ATEX certified and lubrication free
Benefits
Air motors’ heavy-duty characteristics enhance a sustainable use
The Air Motors range proposes versatile solutions in any kind of industrial environment
Chicago Pneumatic Air motors range offers long lasting efficiency
The Air Motors range proposes versatile solutions in any kind of industrial environment
Chicago Pneumatic Air motors range offers long lasting efficiency
Features
Low friction design of vane and blade,
Lubrication free design
A Design to sustain stall torque loading indefinitely
A Light and compact planetary gears system
A long and slim design
A range of accessories proposed to facilitate customized assembly.
ATEX certification for zone 2
A specific low air consumption design
a strong starting torque for mobility during operation
Lubrication free design
A Design to sustain stall torque loading indefinitely
A Light and compact planetary gears system
A long and slim design
A range of accessories proposed to facilitate customized assembly.
ATEX certification for zone 2
A specific low air consumption design
a strong starting torque for mobility during operation
| Part number | 2051478414 |
|---|---|
| Model | MR25-480-KL-ATEX |
| Tool category | MR25 (0.16 kW / 0.21 hp) |
| Back head coaxial | no |
| Net weight | 1.65Â lb |
| Air inlet thread size | 1/8″ |
| Free speed | 480Â rpm |
| IP Rating | IP66 |
| European Directives | 2006/42/EC (Annex I, clauses 1.1, 1.2 (excluding 1.2.4.3), 1.3, 1.4, 1.5, 1.6, 1.7), 2014/34/EU |
| European Standards | DIN EN 4414:2010, DIN EN 1127-1:2011, DIN EN 80079-36:2016, DIN EN 80079-37:2016, DIN EN ISO 12100:2010 |
| ATEX certificate number | 9836 4610 00Â |
| Air inlet thread type | BSP |
| ATEX | yes |
| Front nut threaded | no |
| Lubrication free | yes |
| Max. Output Power | 0.21Â hp |
| Output spindle | 0.394″ |
| Stainless steel | no |
| Stall torque | 9.3Â ft.lbs |
| Torque at max. power | 4.6Â ft.lbs |
| Mini starting torque | 6.3Â ft.lbs |
| Air flow at max. capacity | 10.6Â cfm |
| Spindle type | Keyed shaft |
| Shaft loading code | b |
| Reversible | yes |
