Mi-T-M 10000W Inverter Generator GEN-10000-0MM1E

Description

GEN-10000-0MM1E

The ChoreMaster® Series of generators come with a Mi-T-M OHV engine, is equipped with CO detection and designed to provide maximum power for contractors and back-up for power outages.

Alternator: Copper windings

Engine: Recoil start · Electric start – sealed battery included

Frame: Easy to remove access panels for spark plug, oil and air cleaner · Handle and wheels · Outlet covers

Components: Equipped with CO detector · Automatic shutdown · Fuel shut-off valve · Idle control · Digital display for voltage, hertz, run hours and total hours · USDA/USFS-approved spark arrestors

Noise level tested at seven meters (75% load). Rating represents minimum noise level rating.

Specifications

• Max. AC Output

  10000 watts

• Rated AC Output

  9000 watts

• Displacement/ Engine

  500cc Mi-T-M OHV

• Alternator

  Brushed, 120V/240V, 60Hz

• Max. Amps (120V/240V)

  83.3/41.7

• Cont. Amps (120V/240V)

  75.0/37.5

• Receptacles

  (2) 120V, 20A GFCI Duplex; (1) 120V, 30A Twist Lock; (1) 120V/240V, 30A Twist Lock

• Circuit Breakers

  (2) 20A Toggle Circuit Breakers, Single Pole; (2) 30A Toggle Circuit Breakers, Single Pole

• Rated Speed

  3600 RPM

• Decibel Rating

  82.9

• Fuel Capacity

  7.1 gallon

• Run Time (At Full Load)

  5.5 hours

Weights & Dimensions

• Net Weight

  209.00 lbs.

• Shipping Weight

  235.00 lbs.

• Length

  39.10 in.

• Width

  28.70 in.

• Height

  30.60 in.
